CH10x38 gPV 4A/1000V DC UL

In vendor's stock Not Available

Estimate delivery time to our warehouse: By request

Technical Information

Item condition	New
Manufacture name	CH10x38 gPV 4A/1000V DC UL
Brand	ETI
ETIM	EC002704
Size	10x38 mm

Packing details

Packing level 1	3838895528692, 3838895528692
Packing level 2	3838895528692, 3838895528692
Packing level 3	3838895528708, 3838895528708
Packing level 4	3838895528692, 3838895528692

Description

Fuse link, CH10x38gPV 4A 1000V UL, Breaking capacity DC (kA) 10, Characteristics gPV, Designed for Protection of PV installations, Dimensions 10x38, Operating joule integral (A2s) 12, Power dissipation (W) 1,25, Power dissipation (0,7xIn) (W) 0,52, Prearcing joule integral (A2s) 4, Product group Special purpose fuses, Product subgroup PV, Rated current (A) 4, Rated DC voltage (V) 1000, Size CH10, Type CH
