Modular Jack Socket Centre Plate LS, 1-Gang, For Modular Jack Sockets, Stainless Steel, 70 mm x 70 mm, Snap-on Fixing, With Inscription Field, EMT
Order only
EAN: 4011377178328
MPN: ES1969-15NAWE
Package: 1
Box: 10
Price (excl. VAT)
36,73 €
per unit
MOQ: 1
EDT to our warehouse: 2-4 weeks
Price valid until 31.12.26 or while in stock
Technical Information
| Item condition | New |
| Manufacture name | Centre plate for MJ f. 1 socket ES1969-15NAWE |
| Brand | Jung |
| Categories |
Ethernet Wall Plates
|
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8538 9099 00 |
| ETIM | EC000018 |
| Mounting method | Surface mounted (plaster) |
| Assembly arrangement | Other |
| Utilization | Modular Jack |
| Outlet direction | Straight |
| Suitable for number of connectors | 1 |
| Shielded buses | No |
| Suitable for degree of protection (IP) | IP20 |
Packing details
| Packing level 1 | 4011377178328 |
| Packing level 2 | 4011377178328 |
Other Technical data
| Colour | Stainless steel |
| Halogen free | Yes |
| With hinged lid | No |
| Surface protection | Other |
| With strain relief | No |
| Material quality | Stainless steel |
| Imprintable label | With indication plate |
| Material | Metal |
| Type of fastening | Clamp mounting |
| Shielded housing | No |
| Luster terminal | No |
| RAL-number (similar) | 0 |
| With dust cover | No |
| With imprint | No |
| With buses/couplings | No |
| Support ring | Yes |
| Transparent | No |
| Surface finishing | Matt |
| Device width | 70 mm |
| Device height | 70 mm |
| Device depth | 0 mm |
| Number of modules (module system) | 0 |
| Min. depth of built-in installation box | 0 mm |
Downloads
Description
Designed for modular jack connectivity in power or data systems.Surface-mounted plate intended for straightforward installations. Material metal, stainless steel.Halogen-free construction.Matt surface finishing.Dimensions 70 mm width, 70 mm height, 0 mm depth.IP20 protection rating.Clamp mounting fastening method.Includes support ring and indication plate for labeling purposes without imprinting feature provided.Straight outlet alignment designed without hinged lids or dust covers
