Cable gland KVR M25-MGM/sw
Order only
Price (excl. VAT):
3,10 €
EAN: 4013902932573
MPN: 22702501
Package: 1
Box: 25
Pallet: 16200
Estimate delivery time to our warehouse (approx.):
2-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | Cable gland KVR M25-MGM/sw |
| Brand | Spelsberg |
| Categories |
Standard Cable Glands
|
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 3926 9097 00 |
| Model | Straight |
| Thread length | 11 mm |
| Material quality | Polyamide (PA) |
| Thread type | Metric |
| Material | Plastic |
| Hexagon angular dimension | 31.5 mm |
| Suitable for cable diameter | 9-16 mm |
| Degree of protection (IP) | IP68 |
| Nominal thread size inch/gas pipe thread | Other |
| Nominal thread size metric/PG | 25 |
Packing details
| Packing level 1 | 4013902932573 |
| Packing level 2 | 4013902353699 |
| Packing level 3 | 4013902932573, 4013902335534 |
| Packing level 4 | 4013902932573, 4013902335541 |
Other Technical data
| Colour | Black |
| Halogen free | Yes |
| Shock resistant | Yes |
| RAL-number | 9005 |
| Surface protection | Untreated |
| Bend radius protection/trumpet flare | No |
| With strain relief | Yes |
| Screened | No |
| EMC-version | No |
| Glass-fibre reinforced | Yes |
| Type of sealing | Sealing ring |
| Operating temperature | -25-100 °C |
| Pitch thread | 1.5 mm |
| Explosion-tested version | No |
| Flat cable coupling | No |
| Multi seal area | No |
| With locknut | Yes |
| Separable screw gland | No |
| For Ex-zone gas | None |
| For Ex-Zone dust | None |
| For armoured cable | No |
| Snapping in opening | No |
| Wrench width | 28 mm |
