LED panel Biolux HCL PL 625 S 40W tunable white Zigbee
Technical Information
| Item condition | New |
| Manufacture name | LED panel Biolux HCL PL 625 S 40W tunable white Zigbee |
| Brand | LEDVANCE |
| Categories |
Ceiling mounting lamps
Built-in mounting lamps Surface mounting lamps LED Panels 62x62 |
| Country of origin | CN |
| Harmonized System Code | 9405 1190 00 |
| Width | 620 mm |
| Colour housing | White |
| Colour rendering index CRI | 90-100 |
| Length | 620 mm |
| Height/depth | 50 mm |
| Lamp type | LED not exchangeable |
| Impact strength | IK02 |
| Nominal voltage | 220-240 V |
| Degree of protection (IP) | IP20 |
| Colour temperature | 2700-6500 K |
| Max. system power | 40 W |
| Rated luminous flux according to IEC 62722-2-1 | 4400 lm |
| Luminaire efficacy | 110 lm/W |
Packing details
| Packing level 1 | 4058075724563 |
| Packing level 2 | 4058075724570 |
| Packing level 3 | 4058075724563 |
Other Technical data
| Protection class | II |
| Lamp holder | Other |
| Connection type | Push-in clamp |
| Voltage type | AC |
| With movement sensor | No |
| Type of grid | Matt |
| Type of control gear | Electronic ballast |
| Built-in width | 600 mm |
| With light sensor | No |
| Suitable for suspended mounting | Yes |
| Number of poles | 2 |
| Housing material | Aluminium |
| Built-in length | 600 mm |
| Suitable for light line configuration | No |
| Suitable for emergency lighting | No |
| Light outlet | Direct |
| Emergency power supply integrated | No |
| With light source | Yes |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 | No |
| Covering of the luminaire with thermally insulating material possible | No |
| Suitable for number of lamps | 0 |
| Suitable for wall mounting | No |
| Suitable for built-in mounting | Yes |
| With control gear | Yes |
| Suitable for workplace according to EN 12464-1 | Yes |
| Suitable for surface mounting | Yes |
| Nominal current | 190 mA |
| With air slots | No |
| Constant light output (CLO) | No |
| IFTTT support available | Yes |
| Type of wiring | Ending |
| Rated life time L70/B50 at 25 °C | 50000 h |
| Rated life time L80/B10 at 25 °C | 40000 h |
| Rated life time L90/B10 at 25 °C | 25000 h |
| Colour consistency (McAdam ellipse) | SDCM3 |
| Photobiological safety according to EN 62471 | RG0 |
| Rated ambient temperature according to IEC62722-2-1 | -20-40 °C |
| Filament test according to IEC 60695-2-11 | 650 °C - 30 s |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | No |
| Dimming DMX | No |
| Dimming potentiometer (integrated) | No |
| Dimming GPRS | No |
| Dimming LineSwitch | No |
| Dimming manufacturer's proprietary system | Yes |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off | No |
| Dimming phase cut-on | No |
| Dimming programmable | Yes |
| Dimming RF | No |
| Dimming Sine Wave Reduction | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | Yes |
| Dimming with push-button | No |
| No dim function | No |
| Light distributor | Diffuser lens/optic/panel |
| Dimming depending on control gear | Yes |
| Dimming DSI | No |
| Operation by Bluetooth | No |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Max. number of luminaires per miniature circuit breaker C16 | 74 |
| Max. number of luminaires per miniature circuit breaker B16 | 74 |
| Dimming DALI-2 | No |
| Colour temperature adjustable | Continuously variable |
| Luminous flux adjustable | No |
| Beam angle adjustable | No |
| Exchangeable control gear | Yes |
| Suitable for ceiling mounting | Yes |
| Built-in height/depth | 50 mm |
| Surface protection housing | Powder coating |
Downloads
Description
Recessed panel luminaires, Tunable White, 110 lm/W, tool-free installation, Zigbee 3.0. Product features: Adjustable color temperature via Tunable White: 2,700…6,500 K. Very high color rendering index Ra: > 90. Initial color consistency: 3 SDCM. High luminous efficacy: up to 110 lm/W. Product benefits: Suitable luminaire for BIOLUX, VIVARES and other Zigbee 3.0 light management systems for simple integration into partner systems. Compatible with VIVARES cloud services. Through-wiring possible with included connector box. Good glare reduction (UGR ≤ 19). Low flicker light thanks to special electronic control gear. 5 years BIOLUX HCL system guarantee when operated as part of a BIOLUX HCL system. Areas of application: Available for grid sizes of 600 x 600 mm, 625 x 625 mm and 1200 x 300 mm. BIOLUX HCL system: Lighting solution for single office areas with up to 48 BIOLUX HCL products. VIVARES Zigbee system: Open-plan office solution for up to 200 BIOLUX HCL products. Hotel and office rooms with little daylight. Nursery and elderly homes. Equipment / Accessories: Connector box with 5-pole terminal included. External control gear included. LEDVANCE BIOLUX app required for commissioning of the BIOLUX HCL system only (available for Android and iOS). LEDVANCE VIVARES app for project planning and required for commissioning of the VIVARES ZIGBEE system only (available for Android and iOS). Accessories for several mounting options available.
