LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection

LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection image 1

LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection image 2

LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection image 3

LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection image 4

LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection image 5

LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection image 6

LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection image 7

LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection image 8

LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection image 9

LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection image 10

LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection

Order only

EAN: 4015081066391

MPN: 106876

Package: 1

Box: 2

Price (excl. VAT)

30,80 €

per unit

MOQ: 1

EDT to our warehouse: 1-4 weeks

Price valid until 31.12.26 or while in stock

Technical Information

Item condition	New
Manufacture name	LS-S11-ZB Safety position switch, 1N/O+1N/C, insulated material, +actuator ZB, screw connection
Brand	EATON
Categories	Limit Switches
Country of origin*	DE
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8536 5080 00
ETIM	EC000030
Switching function	Slow-action switch
Rated operation current Ie at AC-15, 230 V	6 A
Rated operation current Ie at DC-13, 230 V	0.3 A
Suitable for safety functions	Yes
With status indication	No
Type of control element	Other
Rated operation current Ie at AC-15, 24 V	10 A
Rated operation current Ie at DC-13, 125 V	0.8 A
Rated operation current Ie at DC-13, 24 V	3 A

Packing details

Packing level 1	4015081066391
Packing level 2	4015081843213

Other Technical data

Housing material	Plastic
Coating housing	Other
Type of interface for safety communication	None
Type of electric connection	Cable entry metrical
Explosion safety category for gas	None
Explosion safety category for dust	None
Construction type housing	Cuboid
Degree of protection (IP)	IP66
Forced opening	Yes
Number of safety auxiliary contacts	1
Type of interface	None
Output electronic	No
Rated operation current Ie at AC-15, 125 V	6 A
Width sensor	30 mm
Diameter sensor	0 mm
Height of sensor	96 mm
Length of sensor	33.35 mm
Switching function latching	No
Ambient temperature during operating	-25-70 °C
Number of contacts as normally closed contact	1
Number of contacts as normally open contact	1
Number of contacts as change-over contact	0
Alignment of the control element	Other
Degree of protection (NEMA)	Other

Description

Safety position switch, Basic function: Position switches, Safety position switches, Part group reference: LS(4)…ZB, Product range: Safety position switches, Degree of Protection: IP66, Features: Complete unit, Ambient temperature: -25 - +70 °C, Description: With the actuator inserted, the N/O contact is open and the NC contact is closed., Contacts N/O = Normally open: 1 N/O, Contacts N/C = Normally closed: 1 NC, Notes: = safety function, by positive opening to IEC/EN 60947-5-1, Housing: Insulated material, Connection type: Screw terminal, Standards: IEC/EN 60947
