BA-M-PL RED G15 D 25W 12V 5X1 OSRAM
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | BA-M-PL RED G15 D 25W 12V 5X1 OSRAM |
| Brand | OSRAM |
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| ETIM | EC000996 |
| Width | 12 mm |
| Diameter | 0 mm |
| Length | 50 mm |
| Degree of protection (IP) | IP66 |
| Lamp voltage | 12 V |
| Colour temperature | 0 K |
| Lamp power | 25 W |
| Luminous flux | 907 lm |
Other Technical data
| Shape | Other |
| Connection type | Wire |
| Voltage type | DC |
| Energy efficiency class | B |
| Luminous intensity | 0 cd |
| Suitable for traffic lights | No |
| Suitable for variable road signs | No |
| Suitable for rail traffic | No |
| Suitable for matrix information boards | No |
| Number of LEDs | 3 |
| Average nominal lifespan | 30000 h |
| Suitable for general lighting | Yes |
| Suitable for constant current | No |
| Suitable for constant voltage | Yes |
| Operating current | 2 mA |
| External driver required | Yes |
Description
CBP_02.00 Product family benefits, all [calc.]: Uniform illumination at high LED pitches thanks to Square Lens technology. Modules are compatible with BackLED mounting profile. Significantly better application efficiency compared to systems without lenses. Several options for quick and simple mounting: bolting or snap-in. Excellent module efficacy. Very long lifetime. 5 year guarantee. CBP_01.00 Product family features, all [calc.]: Connected with flexible cables. Type of protection (modules): IP66. Color rendering index Ra: > 80. CE marked and UL listed. CBP_03.00 Areas of applicat, all [calc.]: Signage and illuminated advertising. Backlighting of medium size channel letters. Backlighting of single and double-sided light boxes. Permanent outdoor use in enclosed light boxes or channel letters. CBP_08.00 Equipment / Acces, all [calc.]: BackLED mounting profile BA-SM-MP. Several types of OPTOTRONIC© 12 V power supplies available.
