OSRAM

BA-ECO-M-865-G2 13.5W 12V 80X1 OSRAM

Order only Not Available
Estimate delivery time to our warehouse: By request

Technical Information

Item condition New
Manufacture name BA-ECO-M-865-G2 13.5W 12V 80X1 OSRAM
Brand OSRAM
Country of origin* DE
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
ETIM EC000996
Width 12.5 mm
Diameter 0 mm
Length 4173 mm
Degree of protection (IP) IP64
Lamp voltage 12 V
Colour temperature 6500 K
Lamp power 13.5 W

Packing details

Packing level 1 4052899333741

Other Technical data

Colour White
Shape Other
Connection type Wire
Voltage type DC
Luminous intensity 0 cd
Colour of light according to EN 12464-1 Neutral white 3300-5300 K
Average nominal lifespan 35000 h
Operating current 1.08 mA

Description

CBP_02.00 Product family benefits, all [calc.]: PC cover to protect electrical components. Small size for slim channel letters. 2 year guarantee. CBP_01.00 Product family features, all [calc.]: Single bin technology. High color consistency: 4 SDCM. Available with red light color or color temperature: 6,500 K. Type of protection: IP64. Dimensions: 48 mm x 12 mm x 5.5 mm. Wattage per module: 0.65 W. Working voltage: 12 VDC. Luminous flux: 62 lm. CBP_03.00 Areas of applicat, all [calc.]: Small channel letters (letter depth: 60…100 mm).
