AMP S BAS 2900-840 PM MB EVG - Moisture-proof diffuser luminaire

Name: AMP S BAS 2900-840 PM MB EVG - Moisture-proof diffuser luminaire
Brand: Zumtobel
Price: 200.780 EUR
Availability: PreOrder

In stock: No Vendor stock: No Minimal order quantity: 1

Price (excl. VAT):

200,78 €

This price is valid until 24.12.25

EAN: 5037319473961

MPN: 42929137

Package: 1

Pallet: 72

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	AMP S BAS 2900-840 PM MB EVG - Moisture-proof diffuser luminaire
Brand	Zumtobel
Categories	Wall and ceiling luminaires Ceiling mounting lamps Surface mounting lamps
Country of origin	AT
Harmonized System Code	9405 1140 00
Width	92 mm
Colour housing	Other
Colour rendering index CRI	80-89
Length	1100 mm
Height/depth	90 mm
Lamp type	LED not exchangeable
Impact strength	IK03
Nominal voltage	220-240 V
Degree of protection (IP)	IP66
Beam angle	Extreme wide beam >80°
Colour temperature	4000 K
Max. system power	17.5 W
Rated luminous flux according to IEC 62722-2-1	2800 lm
Luminaire efficacy	160 lm/W

Packing details

Packing level 1	5037319473961, 5037319473961
Packing level 2	5037319473961

Other Technical data

Protection class	I
Lamp holder	Other
Conductor cross section	2.5 mm²
Connection type	Push-in clamp
Voltage type	AC
With movement sensor	No
Type of grid	None
Type of control gear	LED operating device current-controlled
With light sensor	No
Suitable for suspended mounting	No
Housing material	Plastic
Suitable for light line configuration	No
Suitable for emergency lighting	No
Light outlet	Direct
Light sharing	Symmetric
With light source	Yes
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24	Yes
Covering of the luminaire with thermally insulating material possible	Yes
Suitable for number of lamps	1
Suitable for built-in mounting	No
With control gear	Yes
Suitable for workplace according to EN 12464-1	No
Suitable for surface mounting	Yes
Colour of light	White
With air slots	No
Constant light output (CLO)	No
IFTTT support available	No
Type of wiring	Ending
Rated life time L70/B50 at 25 °C	100000 h
Colour consistency (McAdam ellipse)	SDCM3
Total harmonic distortion	29
Rated ambient temperature according to IEC62722-2-1	-10-35 °C
Filament test according to IEC 60695-2-11	650 °C - 30 s
Dimming 0-10 V	No
Dimming 1-10 V	No
Dimming DALI	No
Dimming DMX	No
Dimming potentiometer (integrated)	No
Dimming LineSwitch	No
Dimming manufacturer's proprietary system	No
Dimming mains voltage modulation	No
Dimming phase cut-off	No
Dimming phase cut-on	No
Dimming programmable	No
Dimming RF	No
Dimming Sine Wave Reduction	No
Dimming Touch and Dim	No
Dimming Zigbee	No
Dimming with push-button	No
No dim function	Yes
Dimming DSI	No
Unified Glare Ratio (UGR)	20
Operation by Bluetooth	No
Compatible with Apple HomeKit	No
Compatible with Google Assistant	No
Compatible with Amazon Alexa	No
Max. number of luminaires per miniature circuit breaker C16	26
Max. number of luminaires per miniature circuit breaker B16	16
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)	95 %
Lumen maintenance at median useful life of 75,000 h at 25 °C ambient (tq)	95 %
Flickering value Pst LM	1
Colour temperature adjustable	No
Luminous flux adjustable	No
Beam angle adjustable	No
Exchangeable control gear	Yes
Suitable for ceiling mounting	Yes
Power factor	0.87

Downloads

Declaration DOC CE (Declaration of conformity CE) Declaration RoHS Sales brochure

Description

LED Moisture-proof diffuser luminaire with IP66 protection rating and drip-edge effect for minimizing dirt and collection of dust for maximum hygienic requirements. Luminaire input power: 17.5 W, electronic ballast with LED converter; patented InvisiClick for clipless mounting and opening of the cover. Cover and basic diffuser made of impact-resistant polymethylmethacrylate, temperature- and UV-resistant, made as a single injection-molded piece. LED service life lasts 100000 h before luminous flux is reduced to 95% of the initial value. Chromaticity tolerance (initial MacAdam): 3. Luminaire luminous flux: 2800 lm, Luminaire efficacy: 160 lm/W. Colour rendering Ra > 80, colour temperature 4000 K. Luminaire with symmetric distribution (medium beam). Mounting via V2A standard spring clips to ceilings, walls or trunking. 5-pole connector terminal.. ambient temperature: -10°C to +35°C. Approved for indoor use with vertical or horizontal wall mounting (see installation instructions). Note: please contact your consultant if you are planning to use the luminaire in environments with chemical pollutants, high or condensing humidity and major variations in temperature. Complies with International Food Standard specifications. Designed for BESA box. Permissible for use in environments where the deposition of conductive dust on the luminaire can be expected (EN 60598-2-24). Protection class: SC1, 650 °C glow-wire tested, resistant against ammonia and cleaning agents in the food industry. Luminaire wired with halogen-free leads, silicone-free, Impact strength: IK03, Dimensions: 1100 x 92 x 90 mm; weight: 1.7 kg.
