62842 U-WL-500 Room thermostat
Order only
Price (excl. VAT):
187,50 €
EAN: 4011395322987
MPN: 2CKA006800A3117
Package: 1
Estimate delivery time to our warehouse: 4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | 62842 U-WL-500 Room thermostat |
| Brand | ABB |
| Categories |
Bus System Devices (KNX/Modbus)
|
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 9032 1020 00 |
| Assembly arrangement | Control element |
| Bus system KNX | No |
| Bus system radio frequent | No |
| Bus system Powernet | No |
| With bus connection | Yes |
| Other bus systems | free@home |
| Bus system LON | No |
| Bus system KNX radio | No |
| Radio frequent bidirectional | Yes |
Packing details
| Packing level 1 | 4011395322987, 4011395322987 |
Other Technical data
| Mounting method | Flush mounted (plaster) |
| With display | Yes |
| Material quality | Thermoplastic |
| Number of digital inputs | 0 |
| Material | Plastic |
| With anti-theft/dismantling protection | No |
| Manual set point setting | Yes |
| Parallel-service possible | Yes |
| Presence button | Yes |
| Degree of protection (IP) | IP20 |
| With LED indication | No |
| Transparent | No |
| With local operation | Yes |
| Min. depth of built-in installation box | 29.9 mm |
| External sensor | Yes |
Description
Sensor Unit with integrated RTR
Usable within the free@home® eco system
Heating/cooling mode.
Control element with room temperature controller function.
6-button touch control for on-site operation
Additional functions such as temperature adjustment and timer can be set via app.
With temperature display of set-point temperature
RTR function is also available without prior programming (preconfigured).
The integrated RTR can optionally be equipped with a remote sensor in conjunction with temperature sensor 6226/T.
3-wire connection technology (neutral conductor required).
Programming/settings via the Busch-free@home® app next
Device access via app is via Bluetooth or wireless
Communication with the free@home system is wireless.
Matching central plate: 1794 MDRT-xxx
