3M™ Scotchcast™ Resin Kit 92-NBB GS, Size 1, Cross Section 4x2.5-4x16

In stock: No Vendor stock: No Minimal order quantity: 1

Price (excl. VAT):

Price by request

This price is valid while stock lasts

EAN: 4054596836204

MPN: 7100229886

Package: 1

Estimate delivery time at our warehouse (approx.): By request

Technical Information

Item condition	New
Manufacture name	3M™ Scotchcast™ Resin Kit 92-NBB GS, Size 1, Cross Section 4x2.5-4x16
Brand	3M
Categories	Cable End Terminals & Connectors
Country of origin	BE
Harmonized System Code	8546 9090 00
Model	Cast resin
Suitable for	Other
Material insulating material	Plastic
With connection accessories	None
Rated voltage U0/U (Um)	0.6/1 (1.2) kV

Packing details

Packing level 1

4054596836204

Other Technical data

Number of conductors	5
Mining sector approval	No

Downloads

Product data sheet

Description

3M™ Scotchcast™ Resin kit 92-NBB GS is a premium Y-branch electrical splice, suitable up to 1 kV application. It contains the high-performance, epoxy-based, CMR-free 3M™ Scotchcast™ Resin 4 GS that changes colour after the two components of the resin have been correctly mixed. The innovative 3M closed mix & pouring system ensures quick and clean delivery of the resin into the transparent mould body design.3M™ Scotchcast™ Resin kit 92-NBB GS is used for the insulation and mechanical protection of low voltage cable connections up to 1 kV. The three product options from Size 0 to Size 2 cover a range of cable cross sections from 1.5 mm2 to 35 mm2; in addition, Size 1 and Size 2 are also available with a connector included. The innovative design of the 3M™ Scotchcast™ Resin kit 92-NBB GS allows for a fast and clean installation, thanks to the 3M-patented spout integrated to the resin bag and the mould body. Correct cable setting is secured by the complete transparency of the mould. 3M™ Scotchcast™ 4 GS hydrophobic and CMR-free epoxy resin meets IEC 60455-3-8 requirements and is compliant with EU directive 2011/65/EU (RoHS) and EU directive 1907/2007/EC (REACH), guaranteeing the highest grade of electrical insulation for professional use.
