3M™ Cold Shrink Insulator 8429-12, 900-1000 kcmil (500 mm²), 10 per ca

Order only Minimal order quantity: 10

Price (excl. VAT):

56,55 €

This price is valid until 24.12.25

Subtotal: 565,50 € MOQ: 10

EAN: 0054007423898

MPN: 7000031604

Package: 1

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	3M™ Cold Shrink Insulator 8429-12, 900-1000 kcmil (500 mm²), 10 per ca
Brand	3M
Categories	Heat Shrink Tubing
Country of origin	US
Harmonized System Code	4016 9997 90
Model	Thin-walled
Type	Cold-shrink
Inner diameter before heat-shrink	72.4 mm
Inner diameter after heat-shrink	21.3 mm
Nominal diameter inch	Other
Shrink rate	2:1

Packing details

Packing level 1

0054007423898

Other Technical data

Colour	Black
Halogen free	No
Wall thickness after shrinking	4.6 mm
Length	304.8 m
Material	Ethylene-propylene diene monomer rubber (EPDM)
With inner glue	No
UL approval	No

Downloads

Product data sheet

Description

3M™ Cold Shrink Connector Insulators 8420 and 8430 Series are EPDM tubes designed using a unique Cold Shrink delivery system. Products are supplied pre-stretched on a removable core for efficiency and easy of installation. Removal of the core (unwind) after positioning allows the tube to shrink into position forming a moisture-tight seal. The live memory action of the specially formulated material ensures a permanent, durable environmental seal and insulation.3M™ Cold Shrink Connector Insulators 8420 and 8430 Series are useful as primary electrical insulation for all solid dielectric (rubber and plastic) insulated wire and cable splicing rated to 1000 V, both indoor and outdoor. They are often good in providing physical protection and environmental sealing for communication and other non-electrical applications, including sheath repairs. Operating temperature range is -40°C to 90°C (-40°F to 194°F). In applications where the product is continuously exposed to UV radiation it is good to overwrap with e.g. Scotch® Super 33+™ Vinyl Electrical Tape or Scotch® Self-Fusing Silicone Rubber Electrical Tape 70.
