3-conductor through terminal block 2.5 mm² with test option blue

Name: 3-conductor through terminal block 2.5 mm² with test option blue
Brand: WAGO
Availability: PreOrder

Order only Minimal order quantity: 50 Not Available

Estimate delivery time to our warehouse: By request

Technical Information

Item condition	New
Manufacture name	3-conductor through terminal block 2.5 mm² with test option blue
Brand	WAGO
Country of origin*	DE
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8536 9010 00
ETIM	EC000897
Mounting method	DIN rail (top hat rail) 35 mm
Rated voltage	400 V
Type of electrical connection 1	Spring clamp connection
Type of electrical connection 2	Spring clamp connection
Number of levels	1
Number of clamp positions per level	3
Connectable conductor cross section solid-core	0.75-4 mm²
Connectable conductor cross section fine-strand with cable end sleeve	0.75-2.5 mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.25-4 mm²
Connectable conductor cross section multi-wired	0.25-2.5 mm²
Rated current In	16 A

Packing level 1

4050821707509

Colour	Blue
Width	5.2 mm
Height	76.8 mm
Depth	32.9 mm
Operating temperature	105 °C
Inflammability class of insulation material according to with UL94	V0
Closing plate required	Yes
Internally connected stages	FALSE
Material insulation body	Thermoplastic
Explosion-tested version 'Ex e'	No

3-conductor through terminal block 2.5 mm² with test option same profile as 3-conductor disconnect terminal block side and center marking for DIN
