10° ANGLED SURFACE-MOUNTING SOCKET-OUTLET - IP44 - 3P 32A 20-25V 50-60HZ - VIOLET - n.r. - SCREW WIRING
In stock: No
Vendor stock: No
Minimal order quantity: 10
Price (excl. VAT):
11,20 €
Subtotal: 112,00 €
MOQ: 10
EAN: 8011564008526
MPN: GW62466
Package: 1
Box: 20
Pallet: 240
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | 10° ANGLED SURFACE-MOUNTING SOCKET-OUTLET - IP44 - 3P 32A 20-25V 50-60HZ - VIOLET - n.r. - SCREW WIRING |
| Brand | GEWISS |
| Categories |
CEE Sockets
|
| Harmonized System Code | 8536 6990 00 |
| IEC-amperage | 32 A |
| Connection system | Screwed terminal |
| Contact material | Other |
| Degree of protection (IP) | IP44 |
| Voltage according to EN 60309-2 | 20-25 V (50+60 Hz) violet |
Packing details
| Packing level 1 | 8011564008526 |
| Packing level 2 | 8011564008526 |
| Packing level 3 | 8011564008526 |
| Packing level 4 | 8011564008526 |
Other Technical data
| Model | Surface mounted (plaster) |
| RAL-number | 7035 |
| Cable entry | Anti-kink sleeve |
| Number of poles | 3 |
| Insulated mounting | Yes |
| Material | Plastic |
| Type of fastening | External mounting |
| Surface treatment contacts | Nickel-plated |
| Amperage according to UL/CSA (for UL-version) | 0 A |
| Military model | No |
| Identification colour | Purple |
Downloads
Description
IEC 309 BTS Range Extra-low voltage plugs and socket-outlets IEC 309 standard - The IEC 309 BTS range of extra-low voltage plugs and sockets for industrial applications enable machinery and devices that operate on voltages of less than 50 V to be connected.The range includes different versions – straight mobile, 90° connectors, surface-mounting and flush mounting, protected and watertight.Available for currents from 16 to 32 A.
