10° ANGLED FLUSH-MOUNTING SOCKET-OUTLET - IP44 - 2P 32A 20-25V and 40-50V 401-500HZ - GREEN - 11H - SCREW WIRING

In stock: No Vendor stock: No Minimal order quantity: 10

Price (excl. VAT):

8,06 €

This price is valid until 24.12.25

Subtotal: 80,60 € MOQ: 10

EAN: 8011564008403

MPN: GW62280

Package: 1

Box: 20

Pallet: 280

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	10° ANGLED FLUSH-MOUNTING SOCKET-OUTLET - IP44 - 2P 32A 20-25V and 40-50V 401-500HZ - GREEN - 11H - SCREW WIRING
Brand	GEWISS
Categories	CEE Sockets
Harmonized System Code	8536 6990 00
Number of poles	2
Material	Plastic
IEC-amperage	32 A
Connection system	Screwed terminal
Rated voltage	20-50 V

Packing details

Packing level 1	8011564008403
Packing level 2	8011564008403
Packing level 3	8011564008403
Packing level 4	8011564008403

Other Technical data

RAL-number	7035
Cable entry	Other
Rated frequency	401-500 Hz
Surface treatment contacts	Nickel-plated
Amperage according to UL/CSA (for UL-version)	0 A
Angle of plug	Angled
Contact material	Other
Degree of protection (IP)	IP44
Military model	No
Clock hour position	11 h
Identification colour	Green
Voltage according to EN 60309-2	20-25 V / 40-50 V (>400-500 Hz) green
Drill hole distance vertical	60 mm
Drill hole distance horizontal	60 mm
Flange size vertical	85 mm
Flange size horizontal	75 mm

Downloads

Product data sheet

Description

IEC 309 BTS Range Extra-low voltage plugs and socket-outlets IEC 309 standard - The IEC 309 BTS range of extra-low voltage plugs and sockets for industrial applications enable machinery and devices that operate on voltages of less than 50 V to be connected.The range includes different versions – straight mobile, 90° connectors, surface-mounting and flush mounting, protected and watertight.Available for currents from 16 to 32 A.
